Carbon Steel Pipes / Tubes Price List

SIZE" SIZE NB MSL ISMT JSL USL BAO Lontrin SMTM TNRS V&M Wuzi
1/2 15 1,323.53 1,316.18 1,330.88 1,029.41 1,036.76 1,470.59 1,397.06 1,426.47 1,022.06
3/4 20 1,102.94 1,095.59 1,110.29 955.88 963.24 1,250.00 1,176.47 1,205.88 948.53
1 25 955.88 948.53 963.24 882.35 889.71 1,102.94 1,029.41 1,058.82 875.00
1.25 32 911.76 904.41 919.12 852.94 860.29 1,058.82 985.29 1,014.71 845.59
1.5 40 808.82 801.47 816.18 808.82 816.18 955.88 882.35 911.76 801.47
2 50 794.12 786.76 801.47 617.65 625.00 941.18 867.65 897.06 610.29
2.5 65 794.12 786.76 801.47 617.65 625.00 941.18 867.65 897.06 610.29
3 80 794.12 786.76 801.47 617.65 625.00 941.18 867.65 897.06 610.29
3.5 90 794.12 786.76 801.47 617.65 625.00 941.18 867.65 897.06 610.29
4 100 794.12 786.76 801.47 735.29 617.65 625.00 941.18 867.65 897.06 610.29
5 125 794.12 786.76 801.47 735.29 617.65 625.00 941.18 867.65 897.06 610.29
6 150 794.12 786.76 801.47 735.29 617.65 625.00 941.18 867.65 897.06 610.29
8 200 794.12 786.76 801.47 735.29 647.06 654.41 941.18 867.65 897.06 639.71
10 250 794.12 786.76 735.29 647.06 654.41 941.18 867.65 897.06 639.71
12 300 852.94 735.29 647.06 654.41 1,000.00 926.47 955.88 639.71
14 350 852.94 735.29 661.76 669.12 1,000.00 926.47 955.88 654.41
16 400 882.35 661.76 669.12 1,029.41 955.88 985.29 654.41
18 450 882.35 676.47 683.82 1,029.41 955.88 985.29 669.12
20 500 882.35 676.47 683.82 1,029.41 955.88 985.29 669.12
22 550 705.88 713.24 1,176.47 1,029.41 1,132.35 698.53
24 600 705.88 713.24 1,176.47 1,029.41 1,132.35 698.53
Price USD/Ton
All prices are applicable for SCH 40, SCH 60, SCH 80 & SCH XS

Carbon Steel Pipes / Tubes Tolerance Chart

TYPE  OD  Thickness
 SEAMLESS  1/4 inch ~ 36 inch  1.25mm ~ 50mm
ERW   1/8 inch ~ 24 inch  Max 26.5mm
LSAW   219mm ~ 3120mm  3mm ~ 25mm
SSAW  16 inch ~ 64 inch  3mm ~ 25mm

Carbon Steel Pipes / Tubes Wall Thickness

Pipe Size in Inch Schedule 40 Thickness Schedule 10 Thickness Schedule 5 Thickness
O.D.

I.D.

Wall Thickness O.D.

I.D.

Wall Thickness O.D.

I.D.

Wall Thickness
3/4 1.050 0.824 0.113 1.050 0.884 0.083 1.050 0.920 0.065
1 1.315 1.049 0.133 1.315 1.097 0.109 1.315 1.185 0.065
1-1/4 1.660 1.380 0.140 1.660 1.442 0.109 1.660 1.530 0.065
1-1/2 1.900 1.610 0.145 1.900 1.682 0.109 1.900 1.770 0.065
2 2.375 2.067 0.154 2.375 2.157 0.109 2.375 2.245 0.065
2-1/2 2.875 2.469 0.203 2.875 2.635 0.120 2.875 2.709 0.083
3 3.500 3.068 0.216 3.500 3.260 0.120 3.500 3.334 0.083
3-1/2 4.000 3.548 0.226 4.000 3.760 0.120 4.000 3.834 0.083
4 4.500 4.026 0.237 4.500 4.260 0.120 4.500 4.334 0.083
6 6.625 6.065 0.280 6.625 6.357 0.134 6.625 6.407 0.109
8 8.625 7.981 0.322 8.625 8.329 0.148 8.625 8.407 0.109

Carbon Steel Pipes / Tubes Size Chart

NB Size OD 40S 5S 10S S10 S20 S40 S60 XS/80S S80 S100 S120 S140 S160 XXS
mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm
1/8” 10.29 1.2 1.73 2.41
1/4” 13.72 1.7 2.24 3.02
3/8” 17.15 1.7 2.31 3.2
15 1/2” 21.34 2.8 1.7 2.1 2.77 3.73 3.73 4.78 7.47
20 3/4” 26.67 2.9 1.7 2.1 2.87 3.91 3.91 5.56 7.82
25 1” 33.4 3.4 1.7 2.8 3.38 4.55 4.55 6.35 9.09
32 1 1/4” 42.16 3.6 1.7 2.8 3.56 4.85 4.85 6.35 9.7
40 1 1/2” 48.26 3.7 1.7 2.8 3.68 5.08 5.08 7.14 10.2
50 2” 60.33 3.9 1.7 2.8 3.91 5.54 5.54 9.74 11.1
65 2 1/2” 73.03 5.2 2.1 3.1 5.16 7.01 7.01 9.53 14
80 3” 88.9 5.5 2.1 3.1 5.49 7.62 7.62 11.1 15.2
90 3 1/2” 101.6 5.7 2.1 3.1 5.74 8.08 8.08
100 4” 114.3 6 2.1 3.1 6.02 8.56 8.56 11.1 13.5 17.1
125 5” 141.3 6.6 2.8 3.4 6.55 9.53 9.53 12.7 15.9 19.1
150 6” 168.3 7.1 2.8 3.4 7.11 10.97 11 14.3 18.3 22
200 8” 219.1 8.2 2.8 3.8 6.4 8.18 10.3 12.7 12.7 15.1 19.3 20.6 23 22.2
250 10” 273.1 9.3 3.4 4.2 6.4 9.27 12.7 12.7 15.1 19.3 21.4 25.4 28.6 25.4
300 12” 323.9 9.5 4 4.6 6.4 10.3 14.3 12.7 17.5 21.4 25.4 28.6 33.3 25.4
350 14” 355.6 9.5 4 4.8 6.4 7.9 11.1 15.1 12.7 19.1 23.8 27.8 31.8 35.7
400 16” 406.4 9.5 4.2 4.8 6.4 7.9 12.7 16.7 12.7 21.4 26.2 31 36.5 40.5
450 18” 457.2 9.5 4.2 4.8 6.4 7.9 14.3 19.1 12.7 23.8 29.4 34.9 39.7 45.2
500 20” 508 9.5 4.8 5.5 6.4 9.5 15.1 20.6 12.7 26.2 32.5 38.1 44.5 50
550 22” 558.8 9.5 4.8 5.5 6.4 9.5 22.2 12.7 28.6 34.9 41.3 47.6 54
600 24” 609.6 9.5 5.5 6.4 6.4 9.5 17.5 24.6 12.7 31 38.9 46 52.4 59.5
650 26” 660.4 9.5 7.9 13 12.7
700 28” 711.2 9.5 7.9 13 12.7
750 30” 762 9.5 6.4 7.9 7.9 13 12.7
800 32” 812.8 9.5 7.9 13 17.5 12.7
850 34” 863.6 9.5 7.9 13 17.5 12.7
900 36” 914.4 9.5 7.9 13 19.1 12.7

Carbon Steel Pipes / Tubes Weight Chart

Size NPS Pipe O.D. Wall Thickness Pipe I.D. Weight per Foot Standard to XXHY Schedule
Pipe #
Section Modulus Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 0.85 STD 40 .0407 .0158
    0.147 0.546 1.09 XHY 80 .0478 .0122
    0.188 0.464 1.31   160 .0528 .0088
    0.294 0.252 1.72 XXHY   .0577 .0026
3/4 1.05 0.113 0.824 1.13 STD 40 .0705 .0277
    0.154 0.742 1.48 XHY 80 .0853 .0225
    0.219 0.612 1.95   160 .1006 .0153
    0.308 0.434 2.44 XXHY   .1103 .0077
1 1.315 0.133 1.049 1.68 STD 40 .1328 .0449
    0.179 0.957 2.17 XHY 80 .1606 .0374
    0.250 0.815 2.85   160 .1904 .0271
    0.358 0.599 3.66 XXHY   .2136 .0146
1 1/4 1.66 0.140 1.380 2.27 STD 40 .2346 .0777
    0.191 1.278 3.00 XHY 80 .2913 .0666
    0.250 1.160 3.77   160 .3421 .0549
    0.382 0.896 5.22     .4110 .0328
1 1/2 1.90 0.145 1.610 2.72 STD 40 .3262 .1058
    0.200 1.500 3.63 XHY 80 .4118 .0918
    0.281 1.338 4.86   160 .5079 .0730
    0.400 1.100 6.41     .5977 .0494
2 2.375 0.109 2.157 2.64   10 .4205 .1898
    0.154 2.067 3.66 STD 40 .5606 .1743
    0.218 1.939 5.03 XHY 80 .7309 .1534
    0.250 1.875 5.68     .8045 .1434
    0.281 1.813 6.29     .8666 .1344
    0.344 1.687 7.47   160 .9806 .1161
    0.436 1.503 9.04 XXHY   1.1043 .0922
2 1/2 2.875 0.120 2.635 3.53   10 .6870 .2833
    0.203 2.469 5.80 STD. 40 1.0640 .2487
    0.216 2.443 6.14     1.1169 .2435
    0.250 2.375 7.02     1.2468 .2301
    0.276 2.323 7.67 XHY 80 1.3386 .2202
    0.375 2.125 10.02   160 1.6371 .1842
    0.552 1.771 13.71 XXXHY   1.9971 .1280
3 3.50 0.120 3.260 4.34     1.0411 .4336
    0.156 3.188 5.58     1.3122 .4147
    0.172 3.156 6.12     1.4265 .4064
    0.188 3.124 6.66     1.5342 .3984
    0.216 3.068 7.58 STD. 40 1.7241 .3840
    0.250 3.000 8.69     1.9372 .3672
    0.281 2.938 9.67     2.1207 .3521
    0.300 2.900 10.26 XHY 80 2.2253 .3431
    0.438 2.624 14.34   160 2.8774 .2811
    0.600 2.300 18.6 XXHY   3.4243 .2158
3 1/2 4.0 0.120 3.760 4.98   10 1.3776 .5768
    0.226 3.548 9.12 STD. 140 2.3939 .5136
    0.250 3.500 10.02     2.6001 .4998
    0.281 3.438 11.17     2.8562 .4821
    0.318 3.364 12.52 XHY 80 3.1400 .4617
    0.636 2..728 22.87 XXHY   4.8795 .3085
4 4.5 0.120 4.260 5.62   10 1.7612 .7404
    0.156 4.188 7.24     2.2354 .7156
    0.188 4.124 8.67     2.6296 .6942
    0.203 4.094 9.32     2.8173 .6838
    0.219 4.062 10.02     3.0184 .6725
    0.237 4.026 10.80 STD. 40 3.2145 .6613
    0.250 4.000 11.36     3.3611 .6528
    0.281 3.938 12.67   60 3.7021 .6326
    0.312 3.876 13.97     4.0273 .6126
    0.337 3.826 15.00 XHY 80 4.2713 .5972
    0.438 3.624 19.02   120 5.1790 .5361
    0.531 3.438 22.53   160 5.8997 .4822
    0.674 3.152 27.57 XXHY   6.7927 .4054
5 5.563 0.188 5.187 10.80     4.1161 1.0979
    0.219 5.125 12.51     4.7279 1.0716
    0.258 5.047 14.63 STD. 40 5.4500 1.0391
    0.281 5.001 15.87     5.8644 1.0204
    0.312 4.939 17.51     6.4074 .99647
    0.344 4.875 19.19     6.9358 .9696
    0.375 4.813 20.80 XHY 80 7.4300 .9449
    0.500 4.563 27.06   120 9.2534 .8495
    0.625 4.313 32.99   160 10.7976 .7590
    0.750 4.063 38.59 XXHY   12.0954 .6734
6 6.625 0.109 6.407 7.59   5 3.5769 1.6748
    0.134 6.357 9.30   10 4.3475 1.6488
    0.156 6.313 10.79     5.0107 1.6260
    0.188 6.249 12.94     5.9351 1.5937
    0.203 6.219 13.94     6.3804 1.5780
    0.219 6.187 15.00     6.8261 1.5620
    0.250 6.125 17.04     7.6905 1.5306
    0.280 6.065 18.99 STD. 40 8.4958 1.5008
    0.312 6.001 21.06     9.3416 1.4688
    0.344 5.937 23.10     10.111 1.4391
    0.375 5.875 25.05     10.893 1.4082
    0.432 5.761 28.60 XHY 80 12.224 1.3541
    0.500 5.625 32.74     13.711 1.2909
    0.562 5.501 36.43   120 14.9806 1.2346
    0.625 5.375 40.09     16.1821 1.1787
    0.719 5.187 45.39   160 17.8243 1.0977
    0.864 4.897 53.21 XXHY   20.025 .9784
    1.000 4.625 60.13     21.7719 .8727
    1.125 4.375 66.14     23.1237 .7809
