Alloy Steel Pipes / Tubes Chemical Properties

Alloy Steel C Cr Mn Mo P S Si
0.05 – 0.15 1.00 – 1.50 0.30 – 0.60 0.44 – 0.65 0.025 max 0.025 max 0.50 – 1.00

Alloy Steel Pipes/Tubes Meachnical Properties

Tensile Strength, MPa Yield Strength, MPa Elongation, %
415 min 205 min 30 min

Alloy Steel Pipe / Tubes Pressure Rating

NPS OD Sch
(inches) (inches) 10 20 STD 30 XS 40 60 80 100 XXS 120 140 160
3/8 0.675 6606 9147 6606 9147
1/2 0.84 6358 8575 6358 8575 17150 10908
1 1.315 4956 6670 4956 6670 13340 9316
1 1/4 1.66 4133 5638 4133 5638 11276 7380
2 2.375 3177 4498 3177 4498 8995 7097
2 1/2 2.875 3460 4704 3460 4704 9408 6391
3 1/2 4 2769 3896 2769 3896
4 4.5 2581 3670 2581 3670 7339 4769 5782
6 6.625 2071 3195 2071 3195 6390 4157 5318
8 8.625 1420 1829 1574 2841 1829 2307 2841 3375 4971 4085 4613 5147
12 12.75 961 1441 1268 1922 1560 2160 2644 3244 3843 3843 4324 5042
14 14 875 1092 1313 1313 1750 1533 2079 2625 3283 3829 4375 4921
18 18 681 849 1021 1192 1361 1530 2042 2553 3147 3743 4252 4848
20 20 613 919 919 1225 1225 1455 1989 2526 3138 3675 4288 4824
24 24 510 766 766 1147 1021 1405 1978 2489 3126 3700 4210 4786
30 30 510 817 613 1021 817
34 34 450 721 540 901 992
42 42 583 438 729 875

Alloy Steel Pipe / Tubes Weight Chart

Size Other Diameter Pipe I.D. WT Standard to XXHY Weight Section Modulus Schedule
Pipe #		 Gallon
1/2 0.84 0.622 0.109 STD 0.85 .0407 40 .0158
0.546 0.147 XHY 1.09 .0478 80 .0122
0.464 0.188 1.31 .0528 160 .0088
3/4 1.05 0.824 0.113 STD 1.13 .0705 40 .0277
0.742 0.154 XHY 1.48 .0853 80 .0225
0.612 0.219 1.95 .1006 160 .0153
1 1.315 1.049 0.133 STD 1.68 .1328 40 .0449
0.957 0.179 XHY 2.17 .1606 80 .0374
0.815 0.250 2.85 .1904 160 .0271
1 1/4 1.66 1.380 0.140 STD 2.27 .2346 40 .0777
1.278 0.191 XHY 3.00 .2913 80 .0666
1.160 0.250 3.77 .3421 160 .0549
1 1/2 1.90 1.610 0.145 STD 2.72 .3262 40 .1058
1.500 0.200 XHY 3.63 .4118 80 .0918
1.338 0.281 4.86 .5079 160 .0730
2 2.375 2.157 0.109 2.64 .4205 10 .1898
2.067 0.154 STD 3.66 .5606 40 .1743
1.939 0.218 XHY 5.03 .7309 80 .1534
1.875 0.250 5.68 .8045 .1434
1.813 0.281 6.29 .8666 .1344
1.687 0.344 7.47 .9806 160 .1161
2 1/2 2.875 2.635 0.120 3.53 .6870 10 .2833
2.469 0.203 STD. 5.80 1.0640 40 .2487
2.443 0.216 6.14 1.1169 .2435
2.375 0.250 7.02 1.2468 .2301
2.323 0.276 XHY 7.67 1.3386 80 .2202
2.125 0.375 10.02 1.6371 160 .1842
3 3.50 3.260 0.120 4.34 1.0411 .4336
3.188 0.156 5.58 1.3122 .4147
3.156 0.172 6.12 1.4265 .4064
3.124 0.188 6.66 1.5342 .3984
3.068 0.216 STD. 7.58 1.7241 40 .3840
3.000 0.250 8.69 1.9372 .3672
2.938 0.281 9.67 2.1207 .3521
2.900 0.300 XHY 10.26 2.2253 80 .3431
2.624 0.438 14.34 2.8774 160 .2811
3 1/2 4.0 3.760 0.120 4.98 1.3776 10 .5768
3.548 0.226 STD. 9.12 2.3939 140 .5136
3.500 0.250 10.02 2.6001 .4998
3.438 0.281 11.17 2.8562 .4821
3.364 0.318 XHY 12.52 3.1400 80 .4617
4 4.5 4.260 0.120 5.62 1.7612 10 .7404
4.188 0.156 7.24 2.2354 .7156
4.124 0.188 8.67 2.6296 .6942
4.094 0.203 9.32 2.8173 .6838
4.062 0.219 10.02 3.0184 .6725
4.026 0.237 STD. 10.80 3.2145 40 .6613
4.000 0.250 11.36 3.3611 .6528
3.938 0.281 12.67 3.7021 60 .6326
3.876 0.312 13.97 4.0273 .6126
3.826 0.337 XHY 15.00 4.2713 80 .5972
3.624 0.438 19.02 5.1790 120 .5361
3.438 0.531 22.53 5.8997 160 .4822
5 5.563 5.187 0.188 10.80 4.1161 1.0979
5.125 0.219 12.51 4.7279 1.0716
5.047 0.258 STD. 14.63 5.4500 40 1.0391
5.001 0.281 15.87 5.8644 1.0204
4.939 0.312 17.51 6.4074 .99647
4.875 0.344 19.19 6.9358 .9696
4.813 0.375 XHY 20.80 7.4300 80 .9449
4.563 0.500 27.06 9.2534 120 .8495
4.313 0.625 32.99 10.7976 160 .7590
6 6.625 6.407 0.109 7.59 3.5769 5 1.6748
6.357 0.134 9.30 4.3475 10 1.6488
6.313 0.156 10.79 5.0107 1.6260
6.249 0.188 12.94 5.9351 1.5937
6.219 0.203 13.94 6.3804 1.5780
6.187 0.219 15.00 6.8261 1.5620
6.125 0.250 17.04 7.6905 1.5306
6.065 0.280 STD. 18.99 8.4958 40 1.5008
6.001 0.312 21.06 9.3416 1.4688
5.937 0.344 23.10 10.111 1.4391
5.875 0.375 25.05 10.893 1.4082
5.761 0.432 XHY 28.60 12.224 80 1.3541
5.625 0.500 32.74 13.711 1.2909
5.501 0.562 36.43 14.9806 120 1.2346
5.375 0.625 40.09 16.1821 1.1787
5.187 0.719 45.39 17.8243 160 1.0977
4.897 0.864 XXHY 53.21 20.025 .9784
4.625 1.000 60.13 21.7719 .8727
4.375 1.125 66.14 23.1237 .7809

Alloy Steel Pipe / Tubes Tolerance

View Chromoly alloy steel pipes, Alloy Steel Seamless Pipe Supplier, High Strength Low Alloy Steel Pipe Stockist and Seamless Alloy Steel Pipe Manufacturers in India
ASTM A450 Hot rolled Outside Diameter, mm Tolerance, mm
OD≤101.6 +0.4/-0.8
101.6＜OD≤190.5 +0.4/-1.2
190.5＜OD≤228.6 +0.4/-1.6
Cold Drawn Outside Diameter, mm Tolerance, mm
OD＜25.4 ±0.10
25.4≤OD≤38.1 ±0.15
38.1＜OD＜50.8 ±0.20
50.8≤OD＜63.5 ±0.25
63.5≤OD＜76.2 ±0.30
76.2≤OD≤101.6 ±0.38
101.6＜OD≤190.5 +0.38/-0.64
190.5＜OD≤228.6 +0.38/-1.14
ASTM A530 & ASTM A335 NPS Outside Diameter, inch Tolerance, mm
1/8≤OD≤1-1/2 ±0.40
1-1/2＜OD≤4 ±0.79
4＜OD≤8 +1.59/-0.79
8＜OD≤12 +2.38/-0.79
OD>12 ±1%
